The can is designed with two IN ports, so that you can vent crankcase vapor from two different sources. The illustration also shows the use of a vented oil filler cap and a vent/drain fitting for the block, which are available from Yoshifab. Here's an image of the Yoshifab catch can.

2) Oil Catch Can (OCC)-All direct injected cars suffer from Carbon build-up since the fuel isn't passing through the intake valves and rather is being fueled directly into the cylinders. The OCC helps catch carbon before it reaches the intake valves therefore reducing carbon build-up in the intake valves on an N54. 3) Meth Injection

Catch cans are a common PCV system part that sit behind the PCV valve and catch any oil deposits in the gas before it is routed back to the intake system. Essentially minimizing the amount of oil that gets passed back into the intake system. The LT1 did not come from the factory with a stock catch can.

An oil catch can reduce the misuse of oil and allow using these oils again after filtering it from the contaminated air of the engine. Thus, in the long run, the owner of the vehicles might save money. Besides, it helps to keep the engine active and fresh so it works well enough to operate.
